A larger off-grid system for a business shed, job site or farm outbuilding, built around eight 100 W panels in two arrays, five 12 V, 100 Ah lithium batteries and a Xantrex inverter.
Parts
- 4 x Zamp Solar Obsidian 200W solar panel kit (2 x 100W)
- 2 x Victron SmartSolar MPPT 100/30 charge controller
- 5 x Battle Born 100Ah 12V LiFePO4 battery
- 1 x Xantrex PROwatt SW1000 true sine wave inverter
- 1 x Victron SmartShunt 500A/50mV battery monitor
- 1 x Blue Sea 5191 MRBF terminal fuse block, 30 to 300A
- 1 x Blue Sea 5025 ST Blade fuse block, 6 circuit
What it covers
Panel side: same two-array layout as System 5, each array under its controller’s 100 V limit and 440 W rating at 12 V. AC side: the Xantrex inverter is sized for light loads. Larger loads need a bigger inverter, which this list does not include. A five battery bank also needs fusing and cable sized for it, which are not in this list.
The parts list is checked against manufacturer ratings. It is not an engineered design, a permitted installation or a promise of runtime. Cable, mounts and the fuses that go in the fuse blocks are not in this list.
