System 1
RV 200W
Two 100 W panels and one lithium battery. Watch the battery from your phone.
- Solar
- 200 W
- Battery
- 1 x 100 Ah
- Inverter
- 375 VA, optional
RV, van and off-grid solar
Power your independence.
Solar and battery parts lists for RVs, vans and cabins. Every part is checked against the manufacturer ratings of the others.
Ordering is not open yet. Notify me when we open.
YOUR SPACE. YOUR JOURNEY. YOUR POWER.
System parts list
System 2: RV 400W
- 2 x Zamp Solar Obsidian 200W solar panel kit (2 x 100W)
- 1 x Victron SmartSolar MPPT 100/30 charge controller
- 2 x Battle Born 100Ah 12V LiFePO4 battery
- 1 x Victron Phoenix Inverter 12/800 120V NEMA 5-15R
- 1 x Victron Orion-Tr Smart 12/12-30 non-isolated DC-DC charger
- 1 x Victron SmartShunt 500A/50mV battery monitor
- 1 x Blue Sea 5191 MRBF terminal fuse block, 30 to 300A
Checked against manufacturer ratings. Not an engineered design. See this system
Pick a system.
Seven parts lists for RVs, camper vans, cabins and backup power.
Compare systemsCheck the parts.
Each list is checked against manufacturer ratings, and each part has its own page.
How we check partsGet one email.
Ordering is not open yet. Leave your email and we will write once, when it opens.
Notify me
System parts lists
Start with the system. Add the parts.
System 2
RV 400W
A mid-size RV system. The vehicle charges the batteries while you drive.
- Solar
- 400 W
- Battery
- 2 x 100 Ah
- Inverter
- 800 VA
System 3
RV 600W
Six 100 W panels, a 50 A controller and six protected DC circuits.
- Solar
- 600 W
- Battery
- 2 x 100 Ah
- Inverter
- Xantrex SW1000
System 4
Camper van
Charges from the alternator while you drive, and from solar when you park.
- Solar
- 380 W
- Battery
- 2 x 100 Ah
- Inverter
- 800 VA
System 5
Small shed or cabin
Two 400 W arrays, each with its own Victron controller.
- Solar
- 800 W
- Battery
- 3 x 100 Ah
- Inverter
- Xantrex SW1000
System 6
Fridge and internet backup
A small system for light loads such as a router.
- Solar
- 100 W
- Battery
- 1 x 100 Ah
- Inverter
- 375 VA
System 7
Business shed, job site or farm outbuilding
Eight 100 W panels in two arrays and five lithium batteries.
- Solar
- 800 W
- Battery
- 5 x 100 Ah
- Inverter
- Xantrex SW1000
Shop equipment
Every part, on its own page.
How we check parts
Checked against manufacturer ratings. Explained in plain words.
- Panel voltage stays under the charge controller’s limit, with room for cold mornings.
- Panel watts stay under the controller’s rated solar power at 12 V, where the manufacturer gives one.
- Inverter ratings are listed so you can compare them with the watts on your device labels.
A parts list is not an engineered design.
